782536-01 is a SCB-68A 68-pin female screw terminal to 68-pin female D-SUB, DIN-rail, shielded I/O connector terminal block. The SCB-68A provides a shielded I/O connection for interfacing I/O signals to plug-in data acquisition devices with 68-pin connectors. This terminal block combines with shield cables to provide low-noise signal termination.. Learn how to use the SCB-68, a 68-pin shielded desktop connector block, for data acquisition applications. This manual covers the features, specifications, installation, and warranty of the SCB-68.
