Intended Use Oasis Elite 975 Series 2 Intended Use These instructions apply to the Oasis Elite 975 series awning (hereinafter referred to as "door awning", "awning," or "product"). It is designed for use over RV entry doors. This awning can be installed by one person with brief help from additional personnel. Use these. Wiring Using AMP UNIVERSAL MATE-N-LOK R SOFT SHELL CONNECTOR Form No. 3307909.006 6/02 ©2002 Dometic Corporation LaGrange, IN 46761. Pin 9 Oasis Elite Remote Switch Yellow/White 16 Gauge Pin 10 WeatherPro Remote Switch Yellow 16 Gauge Pin 11 Blank Pin 12 Oasis Elite Motor (+12VDC) Red 16-18 Gauge.
Page 4: Section 1 Wiring SECTION 1 WIRING 3307930 & 3309114 Control Box Kit Using 12VDC Supply Wire Universal MATE-N-LOK Soft Shell Connector 1.1.1 The 12VDC supply wire must be run from the 12VDC supply source to the Control Yellow (10) Yellow/White (9) Oasis WeatherPro Box. Page 5: Motor Connection & Motor A standard telephone cable will not.. View and Download A&E Systems 971 56 Oasis-Elite Series operating instructions manual online.. Page 6 Oasis-Elite 3109717.003 FIG. 7 Electronic Control Kit Wiring Awning Motor FOR OASIS ELITE AWNING Blue Pig Tail To Motor Blue Remote Pink Pink Switch Pig Tail to 12 Gauge Ignition Interlock 12 VDC Supply EXTEND Green/ White Stripe Green.
